Detailed Information
| AC input voltage: | 100V-240V |
| DC output voltage: | 60.9V |
| Output power: | 3000W |
| Discharge power: | Max.100Wx2 |
| Charging current: | Max.60A |
| Battery type: | LiPo/LiHv |
| Number of battery cells: | 6S-14S |
| Balance accuracy: | ±20mV |
| interface type: | AS150U+MX3.0 |
| Size: | 303x150x220mm |
| Weight: | 6.5KG |
| Unit cell voltage | 4.20 V/4.35V |
| Temperature protection | 75 ºC |
| High temperature ambient operating | +40ºC |
| Low temperature ambient operating | 0ºC |
| High temperature storage | +70ºC |
| Low temperature storage | -20ºC |
| Thermal shock | -25ºC to 75ºC, <3min transition, 2.5hours dwell, 200cycle |
