Detailed Information
| Sensor Type | CMOS 2MP |
| Scale | 4:3/16:9 Switchable |
| Tv System | PAL/NTSC Switchable |
| Resolution | 1500TVL |
| FOV | 4:3 FOV-H: 120° FOV-D:150° |
| 16:9 FOV-H: 155° FOV-D:175° | |
| Shutter Speed | Auto |
| Flip | Up, Down, Left and Right |
| Video Output | CVBS Analog Signal |
| Latency | Low to 2ms |
| Minimum Illumination | 0.001Lux |
| White Balance | Auto |
| DNR | 3DNR |
| WDR | 110dB |
| DAY/NIGHT | EXT/Auto/Color/B&W |
| Flight OSD | Voltage/Cam Title/Time |
| Input Voltage | 5V~16V |
| Power Consumption | 115mA±15%@DC12V,270mA±15%@DC5V |
| Language | ENGLISH /中文 |
| Working Temperature | -10°~50°C RH90% MAX |
| Working Humidity | 20~80% |
| Storage Temperature | -20°~70°C |
| Dimension | 22*22mm; 28*22mm(with bracket) |
| Weight | 10.2g(Exclude cable) |
